在濟南服裝廠的設計流程中，設計稿的展現不僅是創意落地的關鍵環節，更是銜接設計理念與生產實踐的橋梁。不同于單純的圖紙繪制，有效的展現方式需兼顧藝術性、精準性與實用性，讓設計細節被版師、工藝師及客戶清晰理解。結合服裝生產的地域特點與行業需求，設計稿的展現可通過以下多元形式實現：

　　In the design process of Jinan Clothing Factory, the presentation of design drafts is not only a key link in the implementation of creativity, but also a bridge connecting design concepts and production practices. Unlike simple drawing, an effective presentation method needs to balance artistry, precision, and practicality, allowing design details to be clearly understood by pattern makers, craftsmen, and clients. Based on the regional characteristics and industry demands of clothing production, the presentation of design drafts can be achieved through the following diverse forms:

　　一、手繪草圖與細節標注

　　1、 Hand drawn sketches and detail annotation

　　手繪仍是設計師捕捉靈感的核心方式。使用馬克筆、水彩或彩鉛在硫酸紙或設計紙上勾勒輪廓，通過線條的虛實變化表現服裝的版型張力 —— 如休閑裝的寬松廓形用流暢弧線呈現，正裝的挺括感則以直線條強化。關鍵細節需放大標注：領口的翻折角度、袖窿的弧度半徑、門襟的紐扣間距等，用箭頭指向配合簡短文字說明（如 “袖口收 3cm 活褶”“腰節處加隱形省道”）。對于濟南本地特色服裝（如融合魯繡元素的中式裝），可在草圖旁附上手繪的刺繡紋樣局部，用不同色彩標注繡線材質與針腳走向，讓傳統工藝細節更易被理解。

　　Hand drawing remains the core way for designers to capture inspiration. Use markers, watercolors, or colored pencils to outline on sulfuric acid paper or professional design paper, and express the tension of clothing patterns through the changes in the virtual and real lines - for example, the loose silhouette of casual wear is presented with smooth curves, while the stiffness of formal wear is reinforced with straight lines. Key details need to be enlarged and labeled: the folding angle of the collar, the radius of the armhole's curvature, the spacing between the buttons on the placket, etc. Use arrows to point to them and provide brief text explanations (such as "3cm pleat at the cuff" and "hidden provincial road at the waist"). For local characteristic clothing in Jinan (such as Chinese style clothing that incorporates Lu embroidery elements), hand drawn embroidery patterns can be attached next to the sketch, with different colors indicating the embroidery thread material and stitch direction, making traditional craftsmanship details easier to understand.

　　二、數字化精確繪圖與效果模擬

　　2、 Digital Accurate Drawing and Effect Simulation

　　數字化工具為設計稿提供精準呈現載體。通過矢量繪圖軟件繪制的款式圖，能精確標注各部位尺寸（如衣長、肩寬誤差控制在 0.5cm 內），并分層展示面料肌理 —— 用漸變填充模擬棉麻的粗糙質感，用點陣圖案表現針織面料的彈性紋路。對于需要展現穿搭效果的設計，可借助圖像合成軟件將平面款式圖與人體模型結合，調整光影層次模擬服裝在不同場景（如日常通勤、正式場合）的穿著狀態。濟南春秋季晝夜溫差大的氣候特點，還可通過數字化繪圖對比同一設計在單穿、疊穿狀態下的版型變化，為多季適配設計提供直觀參考。

　　Digital tools provide precise presentation carriers for design drafts. The style diagram drawn through vector drawing software can accurately label the dimensions of each part (such as clothing length and shoulder width error controlled within 0.5cm), and display the fabric texture layer by layer - using gradient filling to simulate the rough texture of cotton and linen, and using dot matrix patterns to represent the elastic pattern of knitted fabric. For designs that require the display of dressing effects, image synthesis software can be used to combine flat style images with human body models, adjust the light and shadow levels to simulate the wearing state of clothing in different scenes (such as daily commuting and formal occasions). The climate characteristics of Jinan's large temperature difference between day and night in spring and autumn can also be compared through digital drawing to compare the pattern changes of the same design in single and stacked states, providing intuitive reference for multi season adaptation design.

　　三、立體效果與材質結合呈現

　　3、 The combination of three-dimensional effect and material presentation

　　為讓設計稿更貼近實物質感，可采用立體與平面結合的展現方式。在卡紙或亞克力板上制作 1:5 比例的服裝紙樣模型，用磁貼固定可拆卸的領、袖部件，直觀展示結構關系；將面料小樣（如濟南本地常用的粗紡毛呢、純棉府綢）剪貼在設計稿旁，標注紗織密度、色號及洗滌方式，幫助版師選擇匹配的輔料。對于帶有特殊工藝的設計（如抽繩收腰、撞色拼接），可制作簡易坯布小樣，拍攝多角度照片附在設計稿中，用紅線標注省道位置與縫份寬度，讓工藝師清晰把握制作要點。

　　To make the design closer to the physical texture, a combination of three-dimensional and two-dimensional presentation can be used. Make a 1:5 scale clothing pattern model on cardboard or acrylic board, fix the detachable collar and sleeve components with magnetic tape, and visually display the structural relationship; Cut and paste fabric samples (such as commonly used coarse woolen fabric and pure cotton poplin in Jinan) next to the design draft, label the yarn density, color code, and washing method to help the pattern maker choose matching accessories. For designs with special techniques, such as drawstring waist cinching and color blocking splicing, simple fabric samples can be made and multi angle photos can be taken and attached to the design draft. The provincial road position and seam width can be marked with red lines to allow the craftsman to clearly grasp the production points.

　　四、動態與場景化輔助說明

　　4、 Dynamic and scene based auxiliary explanation

　　設計稿的展現還可延伸穿著場景的模擬。用短視頻記錄設計師對著裝效果的講解：手持設計稿站在人體模型旁，比劃衣擺的垂墜弧度、袖口的堆疊效果，同步說明設計靈感（如 “這款風衣的斜插袋設計，參考了濟南老商埠建筑的斜線結構”）。對于系列化設計，可制作場景化拼貼：將不同款式的設計稿與濟南的地域元素（如曲水亭街的石板路、泉城廣場的建筑線條）拼合，用箭頭標注設計細節與地域符號的關聯，讓客戶更易理解服裝的風格定位。此外，附上手寫的工藝流程圖（如 “先鎖邊后輯明線”“刺繡完成后再上拉鏈”），能進一步降低生產環節的溝通成本。

　　The presentation of the design draft can also be extended to simulate the wearing scene. Using short videos to record the designer's explanation of the outfit effect: holding the design draft and standing next to the mannequin, gesturing the sagging curve of the hem and the stacking effect of the cuffs, while simultaneously explaining the design inspiration (such as "The slanted pocket design of this windbreaker refers to the slanted structure of the old commercial port buildings in Jinan"). For serialized design, scenario based collages can be created: combining different styles of design drafts with regional elements of Jinan (such as the stone pavement of Qushuiting Street and the architectural lines of Quancheng Square), using arrows to mark the association between design details and regional symbols, making it easier for customers to understand the style positioning of clothing. In addition, attaching a handwritten process flowchart (such as "lock the edges first, then edit the thread" or "zip up after embroidery") can further reduce communication costs in the production process.

　　濟南服裝廠的設計稿展現，本質是將抽象創意轉化為可執行語言的過程。無論是手繪的靈動、數字化的精準，還是立體模型的直觀，終都服務于 “讓設計被準確解讀” 這一核心目標，在保留創意溫度的同時，為后續的裁剪、縫制提供清晰指引。

　　The design draft presentation of Jinan Clothing Factory is essentially the process of transforming abstract creativity into executable language. Whether it's the agility of hand drawn designs, the precision of digitization, or the intuitiveness of 3D models, they all ultimately serve the core goal of "accurately interpreting designs", while retaining the creative warmth and providing clear guidance for subsequent cutting and sewing.
